成品排水溝
-
?排水溝規格規格號內尺寸(長*寬*高)外尺寸(長*寬*高)壓力等級箅子箅條HT150-Z01-D1000X150X1201000X198X160D400鑄鐵箅子鑄鐵箅條HT150-Z02-D
排水溝規格
| 規格號 | 內尺寸(長*寬*高) | 外尺寸(長*寬*高) | 壓力等級 | 箅子 | 箅條 |
| HT150-Z01-D | 1000X150X120 | 1000X198X160 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT150-Z02-D | 1000X150X180 | 1000X198X220 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT150-Z03-D | 1000X150X240 | 1000X198X280 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT150-Z01-E | 1000X150X120 | 1000X198X160 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT150-Z02-E | 1000X150X180 | 1000X198X220 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT150-Z03-E | 1000X150X240 | 1000X198X280 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT150-Z04-300 | 1000X150X260 | 1000X198X300 | D400 | 鑄鐵箅子 | 鑄鐵箅子 |
| HT150-Z04-320 | 1000X150X280 | 1000X198X320 | D400 | 鑄鐵箅子 | 鑄鐵箅子 |
| HT150-Z04-345 | 1000X150X305 | 1000X198X345 | D400 | 鑄鐵箅子 | 鑄鐵箅子 |
| HT200-Z01-C | 1000X200X180 | 1000X248X225 | C250 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200-Z02-C | 1000X200X240 | 1000X248X285 | C250 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200-Z03-C | 1000X200X300 | 1000X248X345 | C250 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200-Z01-D | 1000X200X180 | 1000X248X225 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200-Z02-D | 1000X200X240 | 1000X248X285 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200-Z03-D | 1000X200X300 | 1000X248X345 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200-Z01-E | 1000X200X180 | 1000X248X225 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200-Z02-E | 1000X200X240 | 1000X248X285 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200-Z03-E | 1000X200X300 | 1000X248X345 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200V-Z01-D | 1000X200X219 | 1000X248X265 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT200V-Z01-E | 1000X200X219 | 1000X248X265 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT300-Z01-D | 1000X305X220 | 1000X365X280 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT300-Z02-D | 1000X305X280 | 1000X365X340 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT300-Z03-D | 1000X305X340 | 1000X365X400 | D400 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT300-Z01-E | 1000X305X220 | 1000X365X280 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT300-Z02-E | 1000X305X280 | 1000X365X340 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
| HT300-Z03-E | 1000X305X340 | 1000X365X400 | E600 | 鑄鐵箅子 | 鑄鐵箅條 |
成品排水溝 2017-9-7 本文被閱讀 4672 次
